Indoor Drainage - Linear / Drop
Drop
A linear shower channel whose grate repeats square modules of circular perforations - a centre hole, an inner ring, and a square border of small, medium and large openings - with solid metal between each cluster.
Product certification is in progress and CE is not claimed. Brochure language should be read with the website compliance page.
Drag to rotate
Drop
Geometric circle-cluster grate
SS304 / SS316
EN 1253 · K3 · tileable height max. 12 mm
Representative model · not to scale
Construction
Inside the channel
FIG. 01 LINEAR CHANNEL CROSS-SECTION
WTI · NOT TO SCALE
An SS304 / SS316 linear shower channel with a removable grate. Tileable height max. 12mm, load class K3. Lengths 600 / 700 / 800 / 900mm (customised on request), width 75mm, height 25mm, with a 50mm pipe height and a Ø50mm vertical outlet. An integrated odour trap is published in the factory brochure.
Load class
K3
Indoor linear shower channels are specified for pedestrian wet rooms under EN 1253, load class K3 (300 kg). They are not classified on the exterior EN 1433 A15–E600 ladder.
Specification
| Material | Stainless Steel 304 / 316 |
|---|---|
| Standard | EN 1253 |
| Load class | K3 (300 kg) |
| Tileable height | max. 12mm |
| Length | 600 / 700 / 800 / 900mm (customised on request) |
| Width | 75mm |
| Height | 25mm |
| Pipe height | 50mm |
| Outlet | W-70 Ø50mm, vertical |
How to specify
Geometric circle-cluster grate
A linear shower channel whose grate repeats square modules of circular perforations - a centre hole, an inner ring, and a square border of small, medium and large openings - with solid metal between each cluster.
EN 1253
Manufactured to comply with EN 1253 - Stainless Steel Floor Drains. Third-party certification is in progress.
Stainless Steel 304 / 316
Stainless Steel 304 / 316 - produced in-house at the Jaipur plant.
• The range
Compared to its siblings
Against Lineo, Oval and Rectanglo, Drop is the only circular-perforated linear grate in the range. Against Tileo, the stainless face stays visible rather than disappearing under tile.
Drop
Vs
Lineo
Geometric circle-cluster grate
Staggered multi-row slot grate
| Drop | Attribute | Lineo |
|---|---|---|
| Circle-cluster perforations | Grate | Staggered multi-row slots |
| Repeating square modules of holes | Openings | Three rows, running with the channel |
| Stainless on show | Finished face | Stainless on show |
| K3 (300 kg) | Load class | K3 (300 kg) |
| max. 12mm | Tileable height | max. 12mm |
| SS304 / SS316 | Material | SS304 / SS316 |
| 600 / 700 / 800 / 900mm | Length | 600 / 700 / 800 / 900mm |
| EN 1253 | Standard | EN 1253 |
| A geometric band, not a slot grate | Specify when | Linear slots that sit with large-format tile |
